Alkota AX4 Belt Drive Series

Part Number: 320AX4
Fuel: Oil
Gallons Per Minute: 3
Painted Coil Wrap
PSI: 2000
BTU/HR: 175,000
HP: 4
Drive: Belt
Volt/Phase: 230/1PH
Portability: Standard
AMPS: 20
Ship Weight: 420 Pounds
Includes: Gun / Wand
Includes: 50′ – 3/8″ Hose

Description

AX4 Series – Compact Hot Water Pressure Washers for Industrial Cleaning

When space is limited but cleaning demands are high, the AX4 Series compact hot water pressure washers deliver unmatched performance. Perfectly suited for tight work environments, these heavy-duty machines provide the powerful cleaning force required for the most challenging industrial pressure washing tasks.

Equipped with a durable belt-driven triplex pump, the AX4 operates at lower RPMs to reduce noise, minimize heat buildup, and extend the life of key components. This ensures quiet, reliable operation without compromising power.

Designed for maximum versatility, the four-wheel frame offers excellent mobility on any surface, making this unit a top choice for professionals who need a portable hot water pressure washer that performs in both indoor and outdoor environments.

Key Features:

Compact design ideal for space-restricted job sites
Belt-driven triplex pump for cooler, quieter performance
Industrial-grade components for heavy-duty use
Four-wheel mobility for easy transport across all surfaces
High-efficiency hot water cleaning for grease, oil, and grime

Upgrade your cleaning capability with the AX4 Series – the perfect combination of power, portability, and precision.

AX4: Electric • Oil Fired • Portable • 4 Non-Flat Wheels • Belt Drive • Tri-Plex Pump • High-Efficiency Electric Motor • Non-Corrosive Float Tank • High-Pressure Detergent Application • Trigger Gun • 96’ Coil • 15°, 25° and 40° Degree Nozzle • Hose Reel Mount Bracket

MODEL	PERFORMANCE	COIL SIZE	BTU	POWER	HP	WT
*216AX4	2.0 GPM / 1600 PSI	14”	175, 000	115V 1 PH 20A	2.3 HP	420
*311AX4	3.0 GPM / 1100 PSI	14”	175, 000	115V 1 PH 20A	2.3 HP	425
*320AX4	3.0 GPM / 2000 PSI	14”	175, 000	220V 1 PH 20A	4 HP	420
420AX4	3.5 GPM / 2000 PSI	14”	350, 000	230V 1 PH 30A	5 HP	470

AX4 XTREME: Add These Xtreme Performance Features to the Already High Quality Ax4 Series: • Stainless Steel Wrapper • Fuel Solenoid • High-Limit Switch • Black Color • 15°, 25° and 40° Degree Nozzle • Dakota Cool Bypass (Patent Pending) • Hose Reel Mount Bracket

MODEL	PERFORMANCE	COIL SIZE	BTU	POWER	HP	WT
*216AX4	2.0 GPM / 1600 PSI	14”	175, 000	115V 1 PH 20A	2.3 HP	420
*311AX4	3.0 GPM / 1100 PSI	14”	175, 000	115V 1 PH 20A	2.3 HP	425
*320AX4	3.0 GPM / 2000 PSI	14”	175, 000	220V 1 PH 20A	4 HP	420
420AX4	3.5 GPM / 2000 PSI	14”	350, 000	230V 1 PH 30A	5 HP	470
