Alkota X4 Hot Water Gas Fired Series
324X4 Portable Series – Specifications & Features
Performance
Flow Rate: 3 GPM (gallons per minute)
Pressure: 2,400 PSI
Pump Type: Oil Bath Crankcase | Triplex Ceramic Plunger
Burner Type: Natural Aspirating (LP or Natural Gas)
Heating Capacity: 240,000 BTU
Power & Electrical
Motor Power: 5 HP
Motor Voltage: 230V
Phase: Single Phase
Amp Requirement: 30 Amps
Special voltages available upon request
Fuel Consumption
Natural Gas: 191 ft³/hr
LP Gas: 2.2 gal/hr
Coil System
Coil Type: Vertical Schedule 80
Coil Length: 126 ft
Chemical & Cleaning System
Chemical Injection: High Pressure | Precise Metered Application
Float Tank: Rust-Resistant Design
Standard Accessories: Trigger Gun | Wand
Optional Accessories:
45 lb LP Bottle with Regulator
Bottle Rack
Adjustable Temperature Control
Hose & Mobility
Hose Length: 50 ft
Hose Diameter: 3/8 in
Wheel Diameter: 13 in (for superior mobility)
Dimensions & Weight
Overall Length: 46.5 in
Overall Width: 32 in
Overall Height (without tank): 47 in
Height (with tank): 49 in
Weight: 545 lbs
X4 Portable Series – LP & Natural Gas-Fired Hot Water Pressure Washers
Industrial Cleaning Power That Goes Where You Go
The X4 Portable Series by Alkota is a mid-size, gas-fired hot water pressure washer designed for ultimate portability and industrial-grade performance. Whether powered by liquid propane (LP) or natural gas, these rugged machines deliver high-pressure hot water cleaning power in a compact, mobile design—perfect for job sites, commercial facilities, and remote applications.
Engineered with a belt-driven triplex pump running at lower RPMs, the X4 ensures quieter operation, cooler running temperatures, and extended equipment life. The durable four-wheel chassis rolls smoothly over a variety of surfaces, making this the go-to portable hot water pressure washer for professionals who demand both performance and mobility.
Key Features:
Hydro-insulated coil for added user safety and efficiency
7-year coil warranty – built to withstand the toughest conditions
Soft Damping System – protects pump, coil, and high-pressure components from shock and vibration
Industrial high-pressure hose with swivel end and bend restrictor
Professional-grade trigger gun with insulation and safety lock
Insulated wand for safe, comfortable operation
Quick-connect spray nozzles for fast changes and cleaning precision
Winterizing valve – protects your system during cold weather
UL and CSA certifications available for safety and compliance
Optional Portability Kits are available to further enhance mobility and make setup even easier on uneven or remote terrain.
Take powerful, portable hot water cleaning to the next level with the Alkota X4 Portable Series—built tough, engineered for performance, and ready for wherever the job takes you.
Gas Fired X4 Series: Electric • LP Fired • Portable • 4 Non-Flat wheels • Belt drive tri-plex pump • High-efficiency electric motor • Non-corrosive float tank• High-pressure detergent application • Trigger gun • Schedule 80 coil•15, 25 & 40 Degree nozzles • Electronic Ignition Standard
| MODEL | PERFORMANCE | COIL SIZE | BTU | POWER REQUIREMENT | HP | WT |
| 216X4PT | 2.0 GPM/1600 PSI | 14” | 240, 000 | 115V 1 PH 20A | 2.3 HP | 535 |
| 311X4PT | 3.0 GPM/1100 PSI | 14” | 240, 000 | 115V 1 PH 20A | 2.3 HP | 535 |
| 320X4PT | 3.0 GPM/2000 PSI | 14” | 240, 000 | 230V 1 PH 20A | 4 HP | 535 |
| 324X4PT | 3.0 GPM/2400 PSI | 14” | 240, 000 | 230V 1 PH 30A | 5 HP | 545 |
| 330X4PT | 3.0 GPM/3000 PSI | 14” | 240, 000 | 230V 1 PH 30A | 6 HP | 545 |
Gas Fired X4 Xtreme Series: Add these Xtreme Performance features to the already high quality X4 Series: • Stainless steel wrapper • High-Limit Switch • Black color in Place of Orange • 15, 25 & 40 Degree nozzles • Electronic Ignition Standard
| MODEL | PERFORMANCE | COIL SIZE | BTU | POWER REQUIREMENT | HP | WT |
| 216X4PT | 2.0 GPM/1600 PSI | 14” | 240, 000 | 115V 1 PH 20A | 2.3 HP | 535 |
| 311X4PT | 3.0 GPM/1100 PSI | 14” | 240, 000 | 115V 1 PH 20A | 2.3 HP | 535 |
| 320X4PT | 3.0 GPM/2000 PSI | 14” | 240, 000 | 230V 1 PH 20A | 4 HP | 535 |
| 324X4PT | 3.0 GPM/2400 PSI | 14” | 240, 000 | 230V 1 PH 30A | 5 HP | 545 |
| 330X4PT | 3.0 GPM/3000 PSI | 14” | 240, 000 | 230V 1 PH 30A | 6 HP | 545 |
| LP bottle rack and clamp (I4202-99013) |
| Portability Kit–45 lb. LP bottle, rack, hose, regulator (I4202-99012A) |
| Pneumatic Wheels in place of Non-Flat Wheels |
| Smart Timer (Auto On / Auto Off 20 sec time delay w/ adj. lockout timer) |
| Auto Shutdown Timer (Manual On / Auto Off w/ adj. timer) |
| Adjustable Temperature Control |
| Stainless Steel Wrapper 14” |
| Stainless Steel Frame |
