Alkota Dry Steam Generators
Product Specifications – Dry Steam Generator
-
Flow Rate: 1 GPM (gallon per minute)
-
Operating Pressure: 100 PSI
-
Air Supply Requirement: 80–100 PSI
-
Motor Voltage: 115V (single-phase)
-
Horsepower: 0.75 HP (3/4 HP)
-
Fuel Source: Kerosene, #1 Diesel, or #2 Diesel
-
Fuel Consumption: 4.5 gallons per hour
-
BTU Rating: 630,000 BTU for rapid steam production
-
Pump Style: Oil Bath Crankcase | Triplex Ceramic Plunger
-
Coil Type: Schedule 80 heavy-duty steel
Control Features:
-
90-second delay on pump shut-off
-
90-second burner start-up delay timer
-
Manual reset high-limit temperature control
-
Oil primary control
-
Pressure gauge
-
Pressure switch
-
Relief valve
-
Steam separator
-
Steam trap
-
Integrated temperature control
-
Built-in thermometer
Dimensions & Weight:
-
Length: 63 inches
-
Width: 29 inches
-
Height: 43 inches
-
Weight: 725 lbs
Dry Steam Generators – Industrial Dry Vapor Steam Cleaning & Thawing Solutions
Alkota’s dry steam generators are powerful, low water volume dry vapor steam cleaners engineered for tough industrial tasks requiring precision, safety, and efficiency. These compact machines produce high-temperature dry steam ideal for specialized cleaning, thawing, and curing operations across multiple industries.
Versatile & Reliable for Demanding Industrial Applications
Whether you’re thawing frozen drains, culverts, tanks, or piping systems, or working on infrastructure repair projects, our dry steam systems offer unmatched performance in the field. With minimal moisture output and high heat, they are trusted by municipalities, manufacturers, and utility contractors nationwide.
Key Applications Include:
-
CIPP Liner Curing: Accelerate the curing process in trenchless pipe and sewer repair using dry steam
-
Frozen Pipe Thawing: Unblock frozen pipelines, valves, and drains safely and quickly
-
Railroad Tank Car Thawing: Used by transit and freight companies to thaw heavy-duty equipment
-
Fuel Tank Degassing: Prepare tanks for welding by safely removing residual gases
-
Municipal Maintenance: Ideal for street, highway, and water department operations
Oil Fired • Electric • Portable • Pneumatic wheels • 14 boiler horsepower (246 only) • Belt drive tri-plex pump • High-efficiency electric motor • Non-corrosive float tank
| MODEL | PERFORMANCE | COIL SIZE | BTU | POWER SOURCE | HP/AMPS | WT. |
| 126 | 1 GPM / 100 PSI | 14” | 390,000 | 115 V 1 PH | 3/4 HP 15 AMPS | 450 |
| 246 | 1 GPM / 100 PSI | 18” | 625,000 | 115 V 1 PH | 3/4 HP 15 AMPS | 725 |
No Options Available
